Horizontal CNC

The DH800L Series Horizontal CNC Machine is a high-precision, heavy-duty CNC machining center designed for complex machining applications in industries such as automotive, aerospace, and industrial machinery. Built with an inverted T-shaped optical-mechanical structure and high-grade HT300 cast iron, the DH800L provides exceptional stability, rigidity, and high-speed performance. This machine is perfect for precision operations like milling, boring, and drilling, offering unparalleled flexibility and efficiency.

1. CNC System: FANUC OI-MF PLUS

2. BT50-190-6000 Belt-Driven Spindle Unit

3. 30T Robotic Tool Changer

4. Workpiece Water Cooling, Star-Top Spray

5. Dual-Directional Spiral Chip Conveyors

6. Tri-Color Light, Work Light

7. Water and Air Guns

8. Fully Enclosed Exterior Protection

For detailed configuration parameters, please refer to the Technical Agreement.

• Sturdy and Reliable Construction: The DH800L features an inverted T-shaped structure and HT300 high-grade cast iron components, ensuring a robust and rigid foundation. This design minimizes vibration and maintains precision under heavy cutting forces, delivering consistent, high-quality machining results.
• High-Power Spindle: Equipped with a BT50 spindle taper, the DH800L supports a maximum spindle speed of 6000 rpm and provides a 15/18.5 kW power range. The spindle's high torque output (143/236 Nm) makes the machine suitable for both light and heavy-duty machining, ensuring high productivity and performance across various materials.
• Large Machining Capacity: With X-axis travel of 1300 mm, Y-axis travel of 1000 mm, and Z-axis travel of 1000 mm, the DH800L is capable of accommodating large workpieces. Its worktable surface dimensions of 800×800 mm and 1500 kg load capacity provide excellent versatility, handling a wide range of components, including molds, automotive parts, and aerospace components.
• Precision and Accuracy: The DH800L offers positioning accuracy of 0.012 mm and repeatability of 0.008 mm, ensuring that every part is machined with high precision. The minimum worktable indexing of 1°/0.001° ensures flexibility in complex operations.
• Efficient Tooling System: The DH800L comes with a Disc-type tool magazine that can hold up to 30 tools. This reduces downtime during operations, making it ideal for high-volume production. The maximum tool size of φ110 mm (full tool diameter) and φ220 mm (adjacent tool diameter) ensures that it can handle a wide range of tooling options.

• Spindle and Motor Upgrades: The DH800L can be customized with various spindle configurations to cater to your specific machining needs, whether you require a higher spindle speed or additional cooling options.
• Worktable Modifications: The worktable can be customized to accommodate larger workpieces, providing flexibility for larger or heavier components.
• Tool Magazine Expansion: For high-production environments, the tool magazine capacity can be expanded to accommodate additional tooling, improving machine efficiency and reducing downtime.

The DH800L Horizontal CNC Machine is ideal for precision machining in a wide range of industries, including:

• Automotive Manufacturing: Producing engine blocks, transmission parts, brackets, and other automotive components.
• Aerospace: Machining aircraft components, turbine blades, airframe parts, and engine housings.
• Industrial Machinery: Ideal for manufacturing parts like valves, pumps, machine frames, and more.
• Mold and Die Making: Suitable for complex molds, casting patterns, and other intricate precision parts.

At Dabai Precision Machine Tool (Jiangsu) Co., Ltd., we uphold strict quality standards for every machine we produce. The DH800L is ISO 9001 certified and undergoes thorough testing to ensure it meets global standards for precision, durability, and performance.

Each DH800L Horizontal CNC Machine is carefully packed to ensure protection during transit. We offer global shipping services, ensuring your machine arrives safely and on time. Our logistics team handles everything from packaging to door-to-door delivery.

• One-Year Warranty: The DH800L comes with a one-year warranty covering parts and labor, ensuring your peace of mind.
• 24/7 Technical Support: Our support team is available around the clock to assist with any technical questions or issues that arise.
• Maintenance Services: We offer regular maintenance packages to ensure your DH800L operates at peak performance for years, minimizing downtime and increasing machine lifespan.
