Product Description
The DV1580L is a 5-axis vertical machining center designed for machining complex parts in aerospace, medical, and automotive industries. Its 5-axis capability allows multiple surfaces to be machined in a single setup, reducing repositioning and improving machining efficiency.
Features
Higher Productivity
±110° tilting rotary table (A/C axes) provides full access to complex surfaces, minimizing re-clamping and boosting overall machining efficiency.
High-Speed Cutting Capability
18,000 RPM spindle (24,000 RPM optional) with HSK-A63 interface, suitable for aluminum, titanium, and hardened alloys up to HRC 52.
Superior Stability During Machining
Mineral cast base ensures high vibration damping and reduces thermal drift for consistent performance in long cycles.
Precision Axis Motion for Complex Parts
Rexroth linear guides and laser-compensated ball screws deliver smooth, stable movement with repeatability up to ±0.003 mm.
Applications
Aerospace
Turbine blades, structural frames, engine housings
Automotive
Lightweight chassis components, transmission molds, EV battery trays
Medical
Titanium orthopedic implants, surgical instrument prototypes
Energy
Hydraulic manifolds, wind turbine hubs, valve bodies
Precision Engineering
Optical mounts, defense-grade housings, composite tooling
Quality Assurance
Standardized Production Control
Manufactured under an ISO 9001:2015 quality management system. Key components such as the spindle, rotary table, and linear guides are recorded with batch and supplier information for traceability.
Pre-Shipment Performance Testing
Each machine is run under load for an extended test cycle before shipment. Geometric accuracy is checked using laser measurement equipment, and spindle vibration and axis motion are verified during the test run.
Third-Party Inspection Option
Independent inspection services (such as SGS or TÜV) can be arranged upon request prior to shipment.
Packaging & Logistics
Export Packaging for Overseas Transport
The machine is wrapped with anti-corrosion film and fixed on a reinforced steel base to prevent movement during sea or land transportation.
Electrical Protection During Shipping
The control cabinet and electrical interfaces are sealed during packing, and exposed connectors are protected to reduce moisture and dust exposure during transit.
Coordinated Shipping Arrangement
Typical production lead time is 15–30 days after order confirmation. Shipment can be arranged under FOB Wuxi or CIF terms, with standard export documents provided.
Pre-Delivery Technical Documents
Foundation layout, utility requirements (such as power and air supply), and basic unpacking instructions are provided to support installation and on-site preparation.
After-Sales Service
Remote Diagnostics & Software Updates
Secure VPN enables real-time monitoring, parameter tuning, and CNC software maintenance.
On-Site Commissioning & Training
Optional turnkey installation by Dabai-certified engineers with 3-day hands-on training covering operation, maintenance, and troubleshooting.
Warranty
36 months: Structural components (bed, column, rotary table)
18 months: CNC system, servo drives, spindle motor
Lifetime: Technical consultation via email or video call
FAQ
What materials can the DV1580L machine effectively?
Aluminum alloys, titanium (Grade 2/5), Inconel 718, stainless steel (up to HRC 52), carbon fiber composites, and engineering plastics (e.g., PEEK, PEI).
What are the facility requirements?
380V ±10%, 3-phase, 50/60 Hz, 65 kVA total power; compressed air at 0.6 MPa; floor load capacity ≥5 t/m².
Is offline simulation supported?
Yes-each machine includes a VERICUT-compatible post-processor and kinematic model for collision-free program validation.
How often does the spindle need servicing?
The direct-drive spindle is sealed-for-life with grease lubrication (20,000-hour design life). Annual visual inspection recommended.
Do you accept trade-ins?
Yes-we provide valuation and trade-in credits for used CNC machines from major brands (e.g., DMG MORI, Mazak, Okuma).
Why Choose Dabai Precision?
✅ 200+ DV-Series Machines operating worldwide
✅ In-House R&D Center for custom solutions
✅ 24/7 Multilingual Support
